ESD P-Type Access Gate with ESD Testing System
Compact and economical ESD access control solution designed for electronics manufacturing areas where space, budget, and flexibility matter. Ensures only ESD-compliant operators enter protected zones by integrating seamlessly with ESD wrist strap and footwear testers.
What Is an ESD P-Type Access Gate?
Open-Frame Swing Gate
Controlled entry without full turnstile
An ESD P-Type gate is an open-frame, swing-style access gate that provides controlled entry without a full turnstile or flap barrier. It is widely used in SMT lines, PCB assembly areas, and electronics plants where moderate access control is required with mandatory ESD testing.
Compared to Tripod or Flap Barrier Gates, P-Type Offers:
Ideal For:
Lower investment with same ESD compliance enforcement
Budget Friendly
Easy Install
How the ESD P-Type Gate Works
ESD Gear Worn
Operator wears wrist strap/footwear
ESD Testing
Tester measures resistance to ground
Result Evaluated
Controller evaluates test result
Pass Status
Gate unlocks and allows entry
Fail Status
Gate remains locked, alerts generated
Data Logged
Entry data logged for compliance
Complete Audit Trail
Entry data is logged for compliance and audits with complete traceability
Key Features of ESD P-Type Access Gate
Integrated ESD wrist strap & footwear testing
Compact and space-saving design
Cost-effective alternative to turnstiles
Swing gate mechanism with electromagnetic lock
Visual & audible PASS / FAIL indication
Supports RFID and biometric integration
Easy retrofit into existing factory layouts
Low maintenance and high reliability
Why Choose an ESD P-Type Gate?
Lower investment compared to turnstiles or flap barriers
Flexible design fits tight factory layouts
Enforces ESD compliance consistently
Provides audit-ready digital logs
Simple installation and maintenance
Cost Savings
Retrofit Install
Product Variants & Models
| Model Code | Gate Width | Lock Type | Recommended Use |
|---|---|---|---|
| RT-ESD-PT-800 | 800 mm | EM Lock | Single-person entry |
| RT-ESD-PT-900 | 900 mm | EM Lock | High comfort access |
| RT-ESD-PT-R | Custom | EM Lock + RFID | Integrated access |
| RT-ESD-PT-B | Custom | EM Lock + Biometric | Controlled zones |
RT-ESD-PT-800
RT-ESD-PT-900
RT-ESD-PT-R
RT-ESD-PT-B
Technical Details
Hardware Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Gate Type | P-Type Swing Access Gate | Structure Material | Powder-coated MS / SS |
| Gate Arm | Acrylic / SS | Locking Mechanism | Electromagnetic Lock |
| Power Supply | 230V AC | Control Voltage | 12V / 24V DC |
| ESD Test Range | 750 KΩ – 100 MΩ | Interface Ports | Relay, RS485, TCP/IP |
| Indicators | LED + Buzzer | Operating Temperature | 0°C to +50°C |
| Installation | Floor / Wall mounted |
Protection Rating
Continuous Operation
Certified Product
Software & System Capabilities
Operator-wise Records
Individual operator ESD test records
Comprehensive Reports
Date-wise and shift-wise reports
Event Logs
PASS / FAIL event logging
Flexible Deployment
Local server or cloud-based monitoring
Data Export
Export reports in Excel / CSV
System Integration
ERP, MES, HRMS integration with API
Ideal Applications
Cost-effective ESD access control for moderate-security manufacturing environments
SMT & PCB Assembly Lines
Surface mount technology production
Electronics Manufacturing Units
General electronics production areas
Test & Inspection Areas
Quality testing and inspection zones
Sub-assembly Zones
Component sub-assembly areas
R&D Labs
Research and development facilities
Retrofit ESD Compliance
Upgrading existing facilities
Perfect for Budget-Conscious Facilities
Get the same ESD compliance enforcement at a fraction of the cost. Ideal for facilities looking to retrofit ESD access control without major infrastructure changes.
Speak with an ESD ExpertCompliance & Standards
Designed to support global ESD and manufacturing compliance
ANSI/ESD S20.20
ESD Control Program
IEC 61340 Series
Electrostatics Standards
ISO 9001
Aligned Processes
Controlled Environments
Production Suitable
Audit Ready
Documentation
Tested Products
What Our Clients Say
Testimonials
Aaron
Production Manager, Electronics Manufacturing Unit
Clark Johnson
Quality Engineer, PCB Assembly Facility
Frequently Asked Questions
Find answers to common questions about our ESD Tripod Turnstile Gates
It is best suited for moderate-security zones. For higher security, tripod or flap barrier gates are recommended.
Yes, it supports wrist strap testing, footwear testing, or both.
Yes, the gate remains locked unless a valid ESD PASS signal is received.
Yes, the system supports easy future integration.
Both on-premise and cloud deployment options are available.
It is suitable for controlled areas; flap barrier gates are recommended for higher cleanroom classifications.
Looking for a Simple & Affordable
ESD Access Control Solution?
The ESD P-Type Access Gate offers reliable ESD compliance enforcement at a fraction of the cost. Perfect for SMT lines, PCB assembly, and retrofit projects.
